• Chassis:
• High loads and long service life through torsion-resistant chassis and low dead loader wagon weight
• Easy coupling through hydraulically operated high-lift drawbar for low drawbar
• Narrow drawbar for good manoeuvrability
• Stable when parked through manual folding jack stand
• Bogie:
• High swing angles for good adaptability to terrain, easy driving over silos and easy towing with and handling on the road through tridem chassis with trailing arm and hydraulic axle compensation of 300 mm
• Clean mudguards and therefore no soiling of road since mudguards are tapered to the outside
• Manoeuvrability, transport with low ground disturbance also at high payloads and low tyre wear through standard follow-up steering
• High stability in the field and on the silo through 2,100 mm axle track width
• Brake system:
• Safe driving, operational safety and high ease of use through standard dual-circuit air brake system
• PTO shaft:
• Overload protection for tractor and loader wagon through standard wide-angle PTO shaft (on one side) with cam clutch
• Intake:
• Clean fodder collection without loss, also of short fodder, through steered pick-up with 2,270 mm intake width
• Suitable for wide swaths
• Double swath roller for ideal material flow even at high driving speeds
• Infinite speed adjustment of pick-up via hydraulic drive
• Rotor:
• Optimum cut and load rate through 1-rotor system with wide cutting rotor (1,840 mm, 850 mm diameter)
• Ideal material flow through very small taper from the pick-up into the cutting groove
• Maximum throughput possible at large width
• Optimum loading of cargo space also at the sides
• Maintenance-free main drive, transmission via powerful planetary gearbox
• Low wear through Hardox tine coating
• Cutting unit:
• Short cut fodder with a theoretical cut length of 34 mm for good compaction in the silo through 53 knives on one level
• Easy and exact cutting for high fodder quality
• Knife shape and position of rotor tines ensure a pulling cut
• Optimum protection, reliable and smooth retraction of knives into the cutting groove through separate foreign-object protection for each knife
• Tool-less and therefore quick and easy removal of individual knives for maintenance or knife change
• Body:
• Easy change of loading method from loader wagon to forage transport trailer through stable body without diagonal brackets and ropes
• No accumulation of crop and reduction of friction forces thanks to a rigid contoured panel body with hydraulically movable hinged front wall and smooth insides and side walls in the front section
• High transport capacity despite compact vehicle size and quick emptying through hydraulically operated, hinged front wall
• Good visibility into body during filling and emptying through large viewing window in the front wall
• Easy harvesting through standard forage loading flap in the front wall
• Reliable mechanical locking of hydraulically operated tailgate also on poor roads
• Optional auto-loading with two measuring points, adjustable from tractor for rapid adaptation to changing operating conditions
• Scraper floor:
• Loading with low force and good product distribution right from the start of loading through short conveying channel and 275 mm scraper floor inclination towards the front
• Long durability and high reserves through four strong round-link steel chains with specially hardened ends
• No chain skipping due to large engagement depth of chain links in the chain sprockets (approx. 95 %)
• No flight skew through paired link elongation
• Reliable crop transport through flights of rectangular tubing
• Easy checking of scraper floor and chain tension through automatic chain tensioner
• Readjusting of chain tension at front under the loader wagon in the area of the cutting unit
• Quick emptying through scraper floor that is hydraulically driven on both sides with feed and return line and high-gear 2-speed control
• Even crop feed ensures a good distribution in the silo
• Operation:
• Easy and safe operation allows high daily output
• High ease of use through ISOBUS operation as standard
• High-lift drawbar and knife bar can additionally be operated from the left side (in driving direction) of the loader wagon for easy coupling or maintenance work

• Chassis:
• Hydraulically adjustable high-lift drawbar for low drawbar
• 2 double-acting cylinders
• Manual folding jack stand
• Bogie:
• 2 braking axles
• Tridem chassis with trailing arms and hydraulic axle compensation
• Maintenance-free cylinder bearings
• 2,100 mm axle track width
• 10-hole wheel connection
• 2 hydraulically lockable follow-up steering axles (1st and 3rd axle)
• Angled mudguards
• Brake:
• Dual-circuit air brake system with ALB regulator, spring actuated
• Intake:
• Steered pick-up
• Intake width 2,270 mm
• Hydraulic drive
• 6 rows of tines with centre support
• 55 mm tine spacing
• Guide comb with 2 swath rollers
• Steered guide wheels with pneumatic tyres
• Rotor:
• 1 spiral-feed rotor with 8 rows of tines
• 850 mm diameter
• 1,840 mm width
• Diameter of rotor drive journal 90 mm
• Hardox tine coating
• Cutting unit:
• 53 knives on one level
• Theoretical cut length 34 mm
• Single knife protection mechanism
• Hydraulic knife control
• Tool-less knife change
• Body:
• Rigid body, galvanized and plastic-coated or painted
• Hydraulically operated, hinged front wall including forage loading flap
• Hydraulically operated tailgate with position indicator
• Steel floor
• Cargo space entry on left side in driving direction
• Scraper floor:
• Lowered by 275 mm towards the front
• Hydraulically driven on both sides via 2-speed spur gearbox
• Feed and return line
• 4 round-link steel chains (14 x 50 mm each, 25 t breaking load per chain)
• Diameter of feed shaft 50 mm
• Drive:
• Walterscheid wide-angle PTO shaft (one side) with cam clutch (2,500 Nm)
• PTO speed 1,000 rpm
• Rotor driven via planetary gearbox
• Operation:
• ISOBUS operation
• Lighting according to EU directives
• Protective equipment according to German employers’ liability insurance association
• EU type approval (CoC)

* We reserve the right to make changes to dimensions, weights and technical data. Dimensions and weights do not necessarily correspond to series versions and are not binding.
