• Suitable for grain, corn maize, rape, corn cob mix (CCM) and many other flowable goods
• Suitable for filling seeders and fertiliser spreaders with seed and fertiliser
• Chassis:
• Very stable frame design and firmly welded body for high loads
• Comfortable, quiet driving characteristics, high stability and off-road capability through low centre of gravity
• Bogie:
• Good all-terrain capability through tandem pendulum suspension unit with four maintenance-free parabolic springs
• High stability through axle cross-section of 130 x 130 mm
• High stability through 2,100 mm axle track width
• Transport with low ground disturbance also at high payloads and low tyre wear through optional follow-up steering
• Brake system:
• Safe driving, operational safety and high ease of use through standard dual-circuit air brake system
• Body:
• Two large viewing windows in the front wall for optimum view into the body
• Fully welded body for high tightness and torsion-resistance
• Inclined surfaces ensure that only minimum amounts of crop can stick to the surfaces
• Gentle crop feed and transfer rate adjustment through adjustable dosing unit above the feed auger
• Complete emptying of transfer trailer through manual residual emptying flap at the lowest point of the body
• Inspection ladder at the back of the body as standard equipment
• Optional TwinBunker (split cargo space system) for filling seed drills with fertiliser and seed
• Optional weighing system for exact transferred quantity measurement
• Tarpaulin for protecting the crop from loss and weather; can optionally be operated from the floor using a crank
• Feed auger:
• Even emptying of the body over the entire length and minimization of broken grain through increasing auger flight pitch from back to front
• Partial emptying of the transfer trailer by closing the dosing unit in the body, independent of the feed and overload auger drive
• Overload auger:
• Transfer rate of up to 400 t/h through large 400 mm diameter
• For road transport and chick change in the field, the overload auger is hydraulically foldable
• Loading also from high vehicles through transfer height of up to 4,800 mm
• Drive train:
• Very rugged drive train with Walterscheid PTO shaft with overload clutch
• A wide range of optional extras allows optimum adaptation to user requirements

• Chassis:
• Very stable frame design with permanently welded body
• Rigid drawbar for low drawbar
• Jost jack stand with 2 speeds
• Bogie:
• 2 rigid braking axles, cross-section 130 x 130 mm
• Tandem chassis with parabolic suspension and swing compensation
• Axle track width 2,100 mm
• 10-hole wheel connection
• Brake:
• Dual-circuit air brake system with ALB regulator
• Body:
• Dimensions: 5,980 x 2,490 mm
• Load height: 3,320 mm
• Manually operated residual emptying flap
• Feed auger:
• Diameter 350 mm
• Auger flights with increasing pitch from back to front
• Dosing unit for continuous feed rate adjustment down to complete stop of material flow
• Overload auger:
• Diameter 400 mm
• Hydraulically foldable
• Transfer height 4,920 mm
• Transfer rate approx. 400 t/h
• Drive:
• Walterscheid PTO shaft with overload clutch
• PTO speed 1,000 rpm
• Lighting according to EU directives
• Protective equipment according to German employers’ liability insurance association
• EU type approval (CoC)

* We reserve the right to make changes to dimensions, weights and technical data. Dimensions and weights do not necessarily correspond to series versions and are not binding.
